Front Left Upper Control Arm with Ball Joint for Mitsubishi - OE 4010A147, Direct Replacement by Chinese Factory Supplier

Premium Suspension Control Arm Assembly, 2-Year / 60,000-Mile Warranty, Perfect Fit for Mitsubishi L200/Triton & Fiat Fullback 2.4L/2.5L/2.8L, Replaces 4010A113 & 6000605877

Introduction

Key Features

  • Exact OE Match: Precision-engineered to replace Mitsubishi OE 4010A147, 4010A113 and 6000605877, direct OEM replacement for front left (driver side) upper suspension position, no modification needed for seamless fit.
  • Durable Construction: Heavy-duty stamped steel housing with anti-corrosion E-coating, paired with high-quality ball joint featuring PTFE bearing and chrome-plated stud. Resists road salt, impact, wear and extreme weather for long-lasting reliability.
  • Optimized Suspension Performance: Pre-assembled with ball joint, rubber bushings and mounting hardware, restores factory wheel alignment, improves vehicle handling and stability, and reduces uneven tire wear effectively.
  • Easy Installation: OE-matched mounting points and perfect dimensional accuracy, professional installation recommended in 60 minutes or less with standard repair tools.
  • Warranty Assurance: Backed by a 2-year / 60,000-mile warranty from our Chinese factory, we stand behind all our Mitsubishi suspension parts with strict quality commitment.

Fitment (Mitsubishi & Fiat Models)

  • Mitsubishi L200 (2015-2023) KJ/KK/KL Series - 2.4L 4N15, 2.5L 4D56, 2.8L 4N18 Diesel Engines
  • Mitsubishi Triton (2015-2022) KJ/KK/KL Series - 2.4L 4N15, 2.5L 4D56, 2.8L 4N18 Diesel Engines
  • Fiat Fullback (2016-2021) - 2.4L 4N15, 2.5L 4D56 Diesel Engines
    Check your vehicle's VIN/engine code for 100% compatibility

Why Choose Us

  • Chinese Factory/Wholesaler: Factory-direct pricing with no middlemen, maximize your profit margins for Mitsubishi replacement parts wholesale/retail.
  • Strict Quality Control: 100% pre-shipment inspection, all parts meet or exceed OEM performance and durability standards.
  • Fast Global Shipping: Stocked in US/EU/Asia warehouses, 3-7 business days delivery for most regions, flexible shipping options for bulk orders.
  • 24/7 Professional Support: Expert team available for fitment inquiries, order tracking and after-sales service, solve all your problems efficiently.

4010A147 Control Arm with Ball Joint for Mitsubishi Triton

Signs You Need to Replace Your Mitsubishi 4010A147 Control Arm

  • Clunking/knocking noises from the front left suspension (especially over bumps, potholes or speed bumps)
  • Uneven tire wear (inner/outer edge wear caused by incorrect wheel alignment)
  • Steering wheel vibration or wandering at high speed, difficult to keep straight
  • Reduced cornering stability, vehicle drifts when turning
  • Excessive ball joint play (more than 1.0mm) detected during routine inspection

Professional Installation Tips

  1. Lift the vehicle on a level surface and support it with jack stands - do not rely on a hydraulic jack alone for safety.
  2. Remove the front left wheel for full access to the upper control arm and suspension components.
  3. Disconnect the stabilizer bar link and separate the ball joint from the steering knuckle with a ball joint separator tool.
  4. Remove the upper control arm mounting bolts, then take off the old and worn control arm completely.
  5. Install the new 4010A147 control arm with OE-matched hardware, torque the mounting bolts to 75-85 Nm and ball joint nut to 50-60 Nm.
  6. Reconnect all components, reinstall the wheel and lower the vehicle slowly.
  7. Perform a professional wheel alignment after installation to ensure optimal handling and tire life.
