This rear wheel brake cylinder 47550‑26130 is an essential hydraulic component for Toyota rear drum‑brake system. Under brake‑fluid pressure, built‑in pistons push brake shoes against brake drum to deliver stable rear braking performance for Toyota Hiace LH122 and Hilux LN147 from 1995‑2005. Constructed with high‑precision cast‑iron housing and premium rubber sealing cups and dust boots, it features outstanding corrosion‑resistance and anti‑leak performance to cope with heavy‑load commercial‑vehicle working conditions. Every unit passes strict hydraulic pressure leak test before shipment, accurate thread ports and mounting holes fully match original assembly for direct bolt‑on installation without further modification. Common failure symptoms include brake‑fluid leakage, spongy brake pedal and insufficient rear‑wheel braking power. It is normally replaced during drum‑brake overhaul, serving as reliable repair spare‑part for Toyota van and pickup rear‑brake maintenance.
| Item | Specification |
|---|
| OE Number | 47550‑26130 |
| Cross OE | 47550‑26140 |
| Type | Rear Wheel Brake Cylinder / Drum Brake Wheel Cylinder |
| Applicable Car | Toyota Hiace LH122,Hilux LN147 2L‑TE /2KD‑FTV 1995‑2005 |
| Material | Cast‑iron housing, rubber sealing cup, dust boot |
| Include | 1 piece rear wheel brake cylinder assembly |
| Warranty | 1 year / 50000 KM |
